Heavy-Duty Gantry Shearing Machine
Get Latest Price| Payment Type: | L/C,T/T |
| Min. Order: | 1 set |
Model No.: Q15-315B Gantry Shearing Machine
Brand: hangli
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pump
Warranty Period: 1 Year
Type Of Machine: Hydraulic Guillotine Shears
Machinable Material: Brass / Copper, Alloy, Carbon Steel, Aluminum, Stainless Steel
Core Selling Point: Competitive Price
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Applicable Industry: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Other
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
The Q15-315B Gantry Shearing Machine is a formidable tool tailored for high-efficiency shearing tasks within heavy industrial environments. Equipped with a robust 315-ton capacity, this machine is specially designed for the swift and precise cutting of substantial quantities of scrap metal, optimizing operations in metal recycling and manufacturing sectors.
This model features a rugged gantry framework that guarantees sustained performance and reliability even in the most demanding situations. The hydraulic system of the Q15-315B is engineered for optimum power and control, allowing for consistent and clean cuts, essential for maintaining quality in processed materials.
Additionally, the Q15-315B incorporates an automatic material handling system that significantly reduces manual labor and enhances workflow efficiency. Safety is also a priority, with comprehensive systems in place including emergency stops and built-in guards that protect operators during the shearing process.
With its advanced operational features and user-friendly controls, the Q15-315B Gantry Shearing Machine stands out as a top choice for businesses requiring a high-performance, durable solution to meet their metal shearing needs. This machine not only boosts productivity but also ensures that operations are conducted safely and smoothly.

| Q15龙门剪切机技术参数/Technical parameters of Q15 gantry shearing machine | |||||
| 型号 Model | 最大剪切力 (KN)Maximum shear force | 刀口宽度(mm)Blade width | 剪切频率(T/M)Shear frequency | 剪料尺寸 Cutting size | 功率(KW)Power |
| Q15-200 | 2000KN | 1200 | 6-8 | 20*1200 | 22 |
| Q15-250A | 2500KN | 1200 | 6-8 | 20*1200 | 22*15 |
| Q15-250B | 2500KN | 1600 | 6-8 | 20*1600 | 22*15 |
| Q15-315A | 3150KN | 1200 | 6-8 | 35*1200 | 22*15 |
| Q15-315B | 3150KN | 1600 | 6-8 | 30*1600 | 22*22 |
| Q15-400 | 4000KN | 1600 | 6-8 | 30*1600 | 22*22 |
| Q15-500 | 5000KN | 1600 | 6-8 | 35*1600 | 30*30 |
