Gantry Shearing Machine Hydraulic
Get Latest Price| Payment Type: | L/C,T/T |
| Min. Order: | 1 set |
Model No.: Q15-500 Gantry Shearing Machine
Brand: hangli
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pump
Warranty Period: 1 Year
Type Of Machine: Hydraulic Guillotine Shears
Machinable Material: Brass / Copper, Alloy, Carbon Steel, Aluminum, Stainless Steel
Core Selling Point: Competitive Price
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Applicable Industry: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Other
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
The Q15-500 Gantry Shearing Machine is engineered for top-tier performance in heavy-duty industrial settings, especially in the metal recycling and processing sectors. With a formidable shearing capacity of 500 tons, this machine is designed to effortlessly handle large volumes of metal, making it indispensable for facilities that deal with substantial amounts of scrap metal.
Constructed with a robust gantry frame, the Q15-500 provides exceptional stability and durability, ensuring precise cuts and consistent performance under continuous operational demands. This machine features a state-of-the-art hydraulic system that maximizes force delivery while maintaining energy efficiency, allowing it to slice through various metals with ease and precision.
Operational safety is a key focus of the Q15-500, which includes comprehensive safety features such as emergency stop mechanisms and extensive protective guards that ensure the well-being of operators. Additionally, its advanced control system enables easy operation and fine-tuning of shearing processes, enhancing both productivity and user experience.
Ideal for use in demanding industrial environments that require high capacity and reliability, the Q15-500 Gantry Shearing Machine stands out as a powerful, efficient, and safe solution for optimizing metal shearing operations, contributing significantly to the efficiency and profitability of metal processing businesses.


| Q15龙门剪切机技术参数/Technical parameters of Q15 gantry shearing machine | |||||
| 型号 Model | 最大剪切力 (KN)Maximum shear force | 刀口宽度(mm)Blade width | 剪切频率(T/M)Shear frequency | 剪料尺寸 Cutting size | 功率(KW)Power |
| Q15-200 | 2000KN | 1200 | 6-8 | 20*1200 | 22 |
| Q15-250A | 2500KN | 1200 | 6-8 | 20*1200 | 22*15 |
| Q15-250B | 2500KN | 1600 | 6-8 | 20*1600 | 22*15 |
| Q15-315A | 3150KN | 1200 | 6-8 | 35*1200 | 22*15 |
| Q15-315B | 3150KN | 1600 | 6-8 | 30*1600 | 22*22 |
| Q15-400 | 4000KN | 1600 | 6-8 | 30*1600 | 22*22 |
| Q15-500 | 5000KN | 1600 | 6-8 | 35*1600 | 30*30 |
