Metal Recycling Baler
Get Latest Price| Payment Type: | L/C,T/T |
| Min. Order: | 1 set |
Model No.: HPM-500 Waste Stainless Steel Baler
Brand: HANG LI
Origin: CHINA
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pump
Warranty Period: 1 Year
Machinable Material: Brass / Copper, Alloy, Aluminum, Carbon Steel, Stainless Steel
Core Selling Point: Competitive Price
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Applicable Industry: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Other
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
The HPM-500 Waste Stainless Steel Baler is a highly efficient and robust machine designed for the recycling of stainless steel scrap. This heavy-duty baler compresses stainless steel waste into compact, easy-to-manage bales, significantly reducing the volume of scrap and facilitating its transportation and storage. Ideal for large recycling centers and manufacturing facilities, the HPM-500 streamlines the recycling process, enhancing productivity and operational efficiency.
With its powerful hydraulic system, the HPM-500 ensures consistent and effective baling, capable of handling large quantities of stainless steel without compromising on performance. This machine produces uniform bales that are optimal for recycling purposes, improving the logistical efficiency of the recycling process and potentially increasing the resale value of the baled materials.
Safety features are integral to the design of the HPM-500, with various mechanisms in place to protect operators during use. These include emergency stop buttons, automatic shut-off systems, and protective guarding, ensuring a safe working environment.
Moreover, the HPM-500 Waste Stainless Steel Baler is designed for ease of use, with intuitive controls and minimal maintenance requirements, making it a practical and reliable solution for businesses seeking to enhance their waste management and recycling capabilities.



| HPM-500卧式不锈钢打包机技术参数/Technical parameters of HPM-500 horizontal stainless steel packing machine | |||||||
| 序号 No. | 参 数 内 容 Number Parameter Content | 备注 Remarks | |||||
| 1 | 侧压油缸 Side pressure oil cylinder | 型 号 model | YG340/280-4300 | 2 pieces | |||
| 公称推力 Nominal thrust | 2500KNx2 | 行 程stroke | 4300MM | ||||
| 2 | 门盖油缸 Door cover oil cylinder | 型 号 model | YG220/160-2040 | 1 piece | |||
| 公称推力 Nominal thrust | 1000KN | 行 程stroke | 2040MM | ||||
| 3 | 开门油缸 Door opening oil cylinder | 型 号 model | YG125/63-150 | 1 piece | |||
| 公称推力 Nominal thrust | 350KN | 行 程stroke | 1100MM | ||||
| 4 | 拔销油缸 Pulling pin oil cylinder | 型 号 model | YG125/63-200 | 2 pieces | |||
| 公称推力 Nominal thrust | 180KN*2 | 行 程stroke | 200MM | ||||
| 5 | 料箱尺寸(长×宽×高)(mm) Bin size (length x width x height) (mm) | 4100*1500*1000 | |||||
| 投料口尺寸(长×宽)(mm) Size of feeding port (length x width) (mm) | 2700*1500*1000 | ||||||
| 6 | 包块尺寸(长×宽×高)(MM)Package size (length x width x height) (MM) | 1500*800*1000 | Customizable | ||||
| 7 | 工作压力 System working pressure(Mpa) | 21.5 (翻包系统 Bag flipping system 6Mpa) | |||||
| 10 | 电动机一 Electric motor one | 型 号 model | Y250M-4 | 功 率power | 37KW | ||
| 转 速 rotating speed | 1450r/min | 数 量 quantity | 2 pieces | ||||
| 11 | 电动机二 Electric motor two | 型 号 model | Y250M-6 | 功 率power | 37KW | 双出轴 Double output shaft | |
| 转 速 rotating speed | 970r/min | 数 量 quantity | 1 piece | ||||
| 12 | 油泵 oil pump | 型 号 model | A7V160 | 压 力 pressure | 31.5Mpa | ||
| 流 量 flow rate | 160ml/r | 数 量 quantity | 3 pieces | ||||
| 13 | 油泵 oil pump | 型 号 model | F40YCY14-1B | 压 力 pressure | 31.5Mpa | ||
| 流 量 flow rate | 40ml/r | 数 量 quantity | 1 piece | ||||
| 由于设备不断更新,参数会有所变动.Due to continuous device updates, parameters may change. | |||||||
